In Stock
Min. : 1
Not available to buy on line? Want the lower wholesale price? Please sendRFQ, we will respond immediately
84533-9 Tech Specifications
CONN FFC TOP 9POS 1.25MM R/A
Product Attribute | Attribute Value |
---|---|
Category | Connectors, Interconnects / FFC, FPC (Flat Flexible) Connectors |
Manufacturer | AMP Connectors / TE Connectivity |
Factory Lead Time | 3 Weeks |
Voltage Rating | 50V |
Pitch | 0.049" (1.25mm) |
Operating Temperature | -40°C ~ 85°C |
Mounting Type | Through Hole, Right Angle |
Material Flammability Rating | - |
Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
Height Above Board | 0.189" (4.80mm) |
Features | - |
Current Rating | 1A |
Contact Finish Thickness | - |
Connector/Contact Type | Contacts, Top |
Actuator Material | - |
Product Attribute | Attribute Value |
---|---|
Part Status | Active |
RoHS Status | ROHS3 Compliant |
Pbfree Code | yes |
Termination | Kinked Pin |
Packaging | Bulk |
Number of Positions | 9 |
Mating Cycles | - |
Locking Feature | - |
Housing Color | - |
Flat Flex Type | FFC |
FFC, FCB Thickness | 0.30mm |
Contact Material | Phosphor Bronze |
Contact Finish | Tin |
Cable End Type | Tapered |
Actuator Color | - |
84533-9 Documents
Download datasheets and manufacturer documentation for 84533-9
-
Datasheets
84533-9.pdf
