0015913327 Tech Specifications
CGRID SMT BKWY HDR TIN 32CKT
Product Attribute | Attribute Value |
---|---|
Category | Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins |
Manufacturer | Affinity Medical Technologies - a Molex company |
Factory Lead Time | 3 Weeks |
Voltage Rating | - |
Style | Board to Board or Cable |
Series | C-Grid® 71308 |
Pitch - Mating | 0.100" (2.54mm) |
Overall Contact Length | - |
Number of Rows | 2 |
Number of Positions | 32 |
Material Flammability Rating | UL94 V-0 |
Insulation Material | Liquid Crystal Polymer (LCP), Glass Filled |
Insulation Color | Black |
Features | Pick and Place |
Current Rating | - |
Contact Shape | Square |
Contact Length - Post | - |
Contact Finish Thickness - Post | 150µin (3.81µm) |
Contact Finish - Post | Tin |
Connector Type | Header, Breakaway |
Product Attribute | Attribute Value |
---|---|
Part Status | Active |
RoHS Status | ROHS3 Compliant |
Pbfree Code | yes |
Termination | Solder |
Shrouding | Unshrouded |
Row Spacing - Mating | 0.100" (2.54mm) |
Packaging | Tube |
Operating Temperature | - |
Number of Positions Loaded | All |
Mounting Type | Surface Mount |
Mated Stacking Heights | - |
Insulation Height | 0.050" (1.27mm) |
Ingress Protection | - |
Fastening Type | - |
Contact Type | Male Pin |
Contact Material | Copper Alloy |
Contact Length - Mating | 0.240" (6.10mm) |
Contact Finish Thickness - Mating | 150µin (3.81µm) |
Contact Finish - Mating | Tin |
Applications | Automotive, General Purpose, Lighting, Medical, Telecommunications |
