TMOV25SP510M Tech Specifications

VARISTOR 820V 20KA SQUARE 28MM

Product Attribute Attribute Value
Category Circuit Protection / TVS - Varistors, MOVs
Manufacturer Hamlin / Littelfuse
Factory Lead Time 3 Weeks
Varistor Voltage (Typ) 820V
Varistor Voltage (Max) 902V
Packaging Bulk
Operating Temperature -55°C ~ 85°C (TA)
Mounting Type Through Hole
Maximum AC Volts 510VAC
Current - Surge 20kA
Product Attribute Attribute Value
Part Status Active
RoHS Status ROHS3 Compliant
Pbfree Code yes
Varistor Voltage (Min) 738V
Series TMOV® 25S
Package / Case Square 28mm, 3 Lead
Number of Circuits 1
Maximum DC Volts 670VDC
Energy 520J
Capacitance @ Frequency 680pF @ 1MHz
View Similar

TMOV25SP510M Documents

Download datasheets and manufacturer documentation for TMOV25SP510M

Others include   "TMOV2"   parts

The following parts include  'TMOV2'

Part # Manufacturer Category Availability
TMOV20R115E Hamlin / Littelfuse TVS - Varistors, MOVs 2661
TMOV20R115M Hamlin / Littelfuse TVS - Varistors, MOVs 2607
TMOV20R130E Hamlin / Littelfuse TVS - Varistors, MOVs 2545
TMOV20R130M Hamlin / Littelfuse TVS - Varistors, MOVs 2757
TMOV20R130M Littelfuse Inc. TVS Varistors
TMOV20R140E Hamlin / Littelfuse TVS - Varistors, MOVs 2520
TMOV20R140E Littelfuse Inc. TVS Varistors
TMOV20R140EL2T7 Hamlin / Littelfuse TVS - Varistors, MOVs 2510
TMOV20R140M Hamlin / Littelfuse TVS - Varistors, MOVs 2633
TMOV20R150E Hamlin / Littelfuse TVS - Varistors, MOVs 2717
