HI2220Q401R-10 Tech Specifications

FERRITE BEAD 400 OHM 2220 1LN

Product Attribute Attribute Value
Category Filters / Ferrite Beads and Chips
Manufacturer Laird Technologies - Signal Integrity Products
Factory Lead Time 3 Weeks
Size / Dimension 0.220" L x 0.200" W (5.59mm x 5.08mm)
Ratings -
Package / Case 2220 (5650 Metric)
Number of Lines 1
Impedance @ Frequency 400 Ohm @ 100MHz
Filter Type Power, Signal Line
Current Rating (Max) 4.5A
Product Attribute Attribute Value
Part Status Active
RoHS Status ROHS3 Compliant
Pbfree Code yes
Series HI
Packaging Tape & Reel (TR)
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Height (Max) 0.136" (3.45mm)
DC Resistance (DCR) (Max) 30 mOhm
View Similar

HI2220Q401R-10 Documents

Download datasheets and manufacturer documentation for HI2220Q401R-10

Others include   "HI222"   parts

The following parts include  'HI222'

Part # Manufacturer Category Availability
HI2220P171R-00 Laird Technologies - Signal Integrity Products Ferrite Beads and Chips 2750
HI2220P171R-00 Laird Technologies Ferrite Beads and Chips 2566
HI2220P171R-00 Laird-Signal Integrity Products Ferrite Beads and Chips
HI2220P171R-00 Steward Ferrite Beads and Chips
HI2220P171R-10 Laird Technologies - Signal Integrity Products Ferrite Beads and Chips 18500
HI2220P171R-10 Laird Technologies Ferrite Beads and Chips 18500
HI2220P171R-10 Laird-Signal Integrity Products Ferrite Beads and Chips
HI2220P251R-00 Laird Technologies - Signal Integrity Products Ferrite Beads and Chips 2647
HI2220P251R-00 Laird Technologies Ferrite Beads and Chips 2515
HI2220P251R-00 Laird-Signal Integrity Products Ferrite Beads and Chips
