JMXHH1G05MSUDSG Tech Specifications

CONN RCPT MALE 5POS SOLDER CUP

Product Attribute Attribute Value
Category Connectors, Interconnects / Circular Connectors
Manufacturer Souriau Connection Technology
Factory Lead Time 3 Weeks
Voltage Rating 230V
Shielding Unshielded
Shell Size - Insert 1-5
Shell Finish -
Packaging Bulk
Operating Temperature -20°C ~ 100°C
Mounting Type Panel Mount
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Manufacturer Standard Lead Time 23 Weeks
Insert Material Polyetheretherketone (PEEK)
Features -
Detailed Description 5 Position Circular Connector Receptacle, Male Pins Solder Cup Gold
Contact Material Copper Nickel
Contact Finish - Mating Gold
Color Gray
Backshell Material, Plating -
Product Attribute Attribute Value
Part Status Active
RoHS Status ROHS3 Compliant
Pbfree Code yes
Termination Solder Cup
Shell Size, MIL -
Shell Material Polyetherimide (PEI)
Series JMX
Orientation G
Number of Positions 5
Mounting Feature Bulkhead - Rear Side Nut
Material Flammability Rating UL94 V-0
Lead Free Status / RoHS Status Lead free / RoHS Compliant
Ingress Protection IP68 - Dust Tight, Waterproof
Fastening Type Push-Pull
Current Rating 7A
Contact Finish Thickness - Mating 19.7µin (0.50µm)
Connector Type Receptacle, Male Pins
Cable Opening -
Applications Industrial, Instrumentation, Medical
